Dräger X-plore® 6570
Benefits
Single-filter full-face mask
standard thread connection Rd40 according to EN 148-1silicone mask body, visor made of triplex or PCto be used with all filters with standard thread connection Rd40
Silicone mask body for safety and wearing comfort
A double sealing frame with threefold sealing edges offers safe protection and a secure fit for almost all face shapes. The mask body is made of durable and hypoallergenic silicone (blue or yellow colour) which provides non-compromising wearing comfort – even during prolonged use.
Large field of vision
The distortion-free lens with 180° wide angle provides a large field of view with excellent periphial vision. The lens is made from impact-proof polycarbonate with either a plastic or stainless steel lens frame available.
Efficient ventilation system
The efficient ventilation system with separate inner mask prevents the visor from misting up and provides a clear view.
Versatile use
The X-plore 6570 is equipped with an Rd40 connection in accordance with EN 148-1 for use of the Dräger X-plore® Rd40 filter series.
5-point harness
The comfortable 5-point head harness not only ensures that the mask can be donned easily and quickly, but is wide enough to prevent any pressure points on the wearer's head.
Simple servicing and logistics
One universal size simplifies logistics and storage. The inside barcode allows for ease of recording and servicing the mask inventory.
Clear voice communication
An integrated stainless steel voice diaphragm facilitates good communication.
KEY FACTS
Product type
Single-port full face mask
Protection against
Particles and / or gases and vapors - depending on the system used
Mask body material
Silicone (skin-friendly)
Sizes
Universal size
Communication system
✗
Technical Data
Dräger-specific Bayonet connection
✗
RA -Standard thread connection Rd40 (according to EN 148-1)
✓
PE-thread connection M45x3 (according to EN 148-3)
✗
ESA-plug-in connection (according to DIN 58600)
✗
P-Dräger plug-in connection
✗
RP-Dräger plug-in connection (closed-circuit)
✗
Features
Dräger X-plore bayonet filters (APR)
✗
Dräger X-plore Rd40 filters (APR)
✓
Dräger X-plore 8000 (PAPR)
✓
Dräger Saver PP (escape unit)
✗
Dräger X-plore 9000 (airline unit)
✓
Dräger PSS series (SCBA)
✗
✗
Approvals
Plexiglas
✗
PC (impact-proof)
✓
Triplex (scratch-proof and chemical resistant)
✓
APEC (impact-proof, increased heat resistance)
✗
APECas (impact-, scratch-proof, increased chemical resistance)
✗
Downloads
Filter Selection Guide, en
This brochure will give you a brief overview of the most important factors to consider when choosing filtering respiratory protection devices. This information can help you protect yourself against harmful substances in the air by selecting the appropriate masks and filters.
Guide for selection and use of filtering devices, en
Guide for selection and use of filtering devices
Product Information: Dräger X-plore® 6570
The Dräger X-plore® 6570 is the high comfort full face mask used by professionals in a wide variety of applications. It is the successor to the Panorama Nova® RA masks, a range which has proven itself over decades of use worldwide. Its robust but flexible and skin-friendly mask body made from silicone features high wearing comfort – even when used for long periods of time.
