Dräger X-plore® 1300
Benefits
Pre-formed disposable dust mask
pre-formed mask body with large interior volume for comfortable wearing and easier speechavailable in all three EN protection classes (FFP1, FFP2, FFP3)
Efficient particle protection
Dräger X-plore 1300 is the new generation of pre-formed particle filtering face pieces for effective protection against fine dust as well as solid and liquid particles. For use in applications where exposure to dust is unavoidable the X-plore 1300 is available in all three EN protection classes FFP1, FFP2 and FFP3. Odour stopping versions equipped with an activated carbon layer are ideal for users that battle with unpleasant nuisance odours.
CoolSAFE™ filter material
The specially developed CoolSAFE™ filter material combines various high-performance filter media to achieve an excellent filter performance. Coarse and fine particles are effectively stopped in the various filter layers. At the same time, the breathing resistance remains very low, allowing the user to work easily and without tiring for longer periods. In addition, the face pieces were subjected to the increased requirements of the (optional) dolomite dust test. Their resistance to clogging under high exposure to dust was successfully tested. During activities with high exposure to dust (e.g. mining), this gives the face pieces a longer service life and reduces costs for the user, while maintaining a high degree of wearing comfort.
VarioFLEX™ head harness with EasyStop
Easy to don/doff and adjust with a pressure-free fit. The continuous-looped tear-proof textile strap eliminates the need for clips – preventing uncomfortable pressure and allergic reactions. EasyStop allows the wearer to individually adjust the harness as required, while ensuring ease of use and a secure, comfortable seal. Experience ultimate comfort with the extra-wide slip-proof harness of the Dräger X-plore 1330.
CoolMAX™ exhalation valve (optional)
Small details, big effect: Breathe easy and comfortably, thanks to the extremely low breathing resistance. The valve directs humid and warm exhaled air away from the user and out of the mask – preventing heat build-up and keeping them cool.
A secure seal
Alongside the filter performance, a secure seal, without leakage, is decisive in how effective the masks' protection really is. The X-plore 1300 is the ideal combination of an ergonomic mask body combined with an integrated nose seal and nose clip. This gives the wearer a tailor-made fit and a secure seal. Additionally, the good seal keeps safety glasses from fogging.
Colour coding for fast recognition of the protection class
Fast recognition without confusion: the colour coded nose clip and valve classify the three EN protection levels dark-blue (FFP1), light-blue (FFP2) and white (FFP3). Providing easy recognition when selecting the right mask.
Special features of X-plore 1330
Practical and comfortable: The VarioFLEX™ head harness with a four-point adjustment and extra-wide textile straps ensures the best possible fit. Quick and easy to use: The straps are arranged for fast donning. An integrated safeguard prevents straps from slipping out of place. Secure and comfortable: Integrated, all-around comfort sealing. Clean and hygienic: Each face piece is individually packaged in its own plastic bag. Individually adjustable: Available in two different sizes S/M and M/L – the right size for different face shapes.
KEY FACTS
Product type
Disposable dust mask
Application
Working in dusty environments
Protection against
Fine dusts, solid and liquid particles
Form of mask body
Pre-formed (with large interior volume for comfortable wearing and easier speech)
Protection classes EN 149
FFP1, FFP2, FFP3
Protection classes NIOSH 42 CFR 84
N95, R95
Colour coding of protection classes EN 149
FFP1: dark blue; FFP2: light blue; FFP3: white
Colour coding of protection classes NIOSH 42 CFR 84
N95: dark blue; R95: light blue
Reusability
✗ (max. one work shift)
Sizes EN
Universal size (FFP1 / FFP2) ; S/M and M/L (FFP3)
Sizes NIOSH
XS (only N95), S/M, ML (not R95 Odor)
Technical Data
Drop-down option
✓
Exhalation valve
Optionally available for all protection classes
Odour-stop version EN
Optionally available for FFP2 and FFP3)
Odour-stop version NIOSH
Optionally available for N95 V and R95
Adjustable length of straps
✓
Features
Mask body
Non-woven fabric (CoolSAFE)
Head straps
Continuous-looped tear-proof textile strap
Approvals
EN 149:2001+A1:2009, (EU) 2016/425
✓
AS/NZS 1716:2012
✓
Dolomite dust test (marking D)
✓
Downloads
Filter Selection Guide, en
This brochure will give you a brief overview of the most important factors to consider when choosing filtering respiratory protection devices. This information can help you protect yourself against harmful substances in the air by selecting the appropriate masks and filters.
Guide for selection and use of filtering devices, en
Guide for selection and use of filtering devices
Product Information: Dräger X-plore® 1300
The Dräger X-plore® 1300 combines proven and reliable respiratory protection with intelligent new ideas ensuring a high level of comfort and ease of use.
