Dräger X-plore® 6300
Benefits
Single-filter full-face mask
standard thread connection Rd40 according to EN 148-1 EPDM mask body, visor made of PMMA to be used with all filters with standard thread connection Rd40
Secure and comfortable fit
The mask body is made from durable and skin-friendly EPDM, with double-layer face seal and triple sealing edges which provides a secure and comfortable seal for every type of face.
Wide field of view
The scratch-proof and distortionfree PMMA plexiglas visor with 180° wideangle ensures a large field of vision with excellent panoramic view.
Efficient ventilation system
The efficient ventilation system with separate inner mask prevents the lens from fogging and ensures good vision.
5-point harness
The comfortable 5-point head harness not only ensures that the mask can be donned easily and quickly, but is wide enough to prevent any pressure points on the wearer's head.
Easy maintenance and logistics
One size fits all which simplifies logistics and stocking. The barcode on the inside simplifies the recording and maintaining of the mask inventory.
Versatile use
The Dräger X-plore 6300 full face mask is equipped with a Rd40 connection in accordance with EN 148-1 and can be combined with the extensive Dräger X-plore® Rd40 filter range.
KEY FACTS
Product type
Single-port full face mask
Protection against
Particles and / or gases and vapors - depending on the system used
Mask body material
EPDM
Sizes
Universal size
Communication system
✗
Technical Data
Dräger-specific Bayonet connection
✗
RA -Standard thread connection Rd40 (according to EN 148-1)
✓
PE-thread connection M45x3 (according to EN 148-3)
✗
ESA-plug-in connection (according to DIN 58600)
✗
P-Dräger plug-in connection
✗
RP-Dräger plug-in connection (closed-circuit)
✗
Features
Dräger X-plore bayonet filters (APR)
✗
Dräger X-plore Rd40 filters (APR)
✓
Dräger X-plore 8000 (PAPR)
✓
Dräger Saver PP (escape unit)
✗
Dräger X-plore 9000 (airline unit)
✗
Dräger PSS series (SCBA)
✗
✗
Approvals
Plexiglas
✓
PC (impact-proof)
✗
Triplex (scratch-proof and chemical resistant)
✗
APEC (impact-proof, increased heat resistance)
✗
APECas (impact-, scratch-proof, increased chemical resistance)
✗
Downloads
Filter Selection Guide, en
This brochure will give you a brief overview of the most important factors to consider when choosing filtering respiratory protection devices. This information can help you protect yourself against harmful substances in the air by selecting the appropriate masks and filters.
Guide for selection and use of filtering devices, en
Guide for selection and use of filtering devices
