Electrochemical DrägerSensor®
Benefits
Long lifetime
The electrochemical are designed to provide a reliable und stable measurement function over a long period of time. The use of resistant plastics, such as PTFE, and the purest catalysts make this possible. Additionally, a huge electrolytic reservoir and large electrode areas provide sufficient reserves for a long lifetime. The construction of the DrägerSensors offers you long stability and a low age-related drift.
Ready for immediate use
All DrägerSensors are factory calibrated with the target gas. These values are saved in the internal, electronic memory. You can use the sensors in the field immediately. For some sensors other tagret gases can be selected from the internal gas library.
Comprehensive range of applications
All sensors have an internal temperature sensor. Between -40°C and +65°C, the temperature influence is compensated for zero and sensitivity. The patented internal pressure compensation balances adverse ambient conditions, such as humidity changes or barometric variation. Due to this fact, you can use the sensors even in high or low pressure. For some sensors you can reduce the disturbing influence of cross-sensitivities by combining selective filters.
Performance features
Low detection limitsOptimised selectivityExcellent accuracy of measurementsFast responseComprehensive self-diagnosis optionsIt is possible to choose between oxygen sensors for partial pressure measurement or volume percent measurementSensors with organic electrolyte for detection limits in lower ppb rangeAcid gas sensor AC with unlimited lifetime, due to refillable electrolyte
Downloads
Electrochemical DrägerSensor Product Information, en
Fast response, high accuracy, great stability, long life. Electrochemical DrägerSensors offer all these benefits. You can use the robust and long-life sensors for the selective measurement of the smallest concentrations of toxic gases and oxygen in ambient air.
FGDS Sensor Brochure, en
When there’s danger in the air ... this can quickly pose a high risk to humans, the environment, and all types of property and systems. Recognize the threat before it is too late.
Explosion Protection Brochure, en-master
Detecting flammable gases and vapours before they become a hazard takes priority over mechanical and electrical explosion-protection measures.
